PN6 Flexible Connector - Expansion Bellow

The PN6 flexible connector features carbon steel flanges and is available with EPDM bellows reinforced with a nylon cord and steel wire. With a working pressure of 6 bar, the 130mm long connectors are suitable for 1.1/4" to 4" piping. The EPDM bellows can withstand temperatures ranging from -20°C to +100°C, while the NBR option is suitable for -20°C to +80°C. These connectors are designed for applications that require movement for expansion or contraction, and can be utilized in various ways.

HD is 12mm

DA is 15°

Ext is 8mm

Comp is 15mm
