PCL Vertex Series Quick Connect Couplings

Description

This is a PCL Vertex series pneumatic quick release coupling, interchangeable with the Series 19. These couplings are designed to be strong and durable with a positive locking mechanism, these are also designed to minimise accidental discconection. This range has a maximum working pressure of 14 bar with a flow capacity of 1210 l/min.  This coupling is valved which is closed when disconnected.

Specifications

• Nominal flow diameter 4.8mm (3/16")
• Flow Capacity is 1210 l/min (43 CFM) measured at 6 bar (87 psi) with a 0.5 bar (7 psi) pressure drop
• Max working pressure 14 bar (200 psi)
• Temperature range -40°C to +100°C (-40°F to +212°F)
